Creating Custom SVGs for SCADA

Creating Custom SVGs for iNDUS SCADA:#

In the dynamic world of automation, visualization tools like SCADA systems play a pivotal role in monitoring and controlling industrial processes. iNDUS, developed by Flovel Energy Private Limited, is a state-of-the-art SCADA system that benefits immensely from scalable and adaptable graphics. To enhance its graphic quality, I have designed several SVG symbols tailored for iNDUS, offering unparalleled clarity and flexibility.

Why SVG Over Traditional Image Formats?#

Scalable Vector Graphics (SVG) is a web-based vector image format that has become the gold standard for dynamic and interactive visual content. Unlike raster image formats like PNG or JPEG, which lose quality when resized, SVGs are resolution-independent. This feature makes them ideal for SCADA systems, where visuals often need to be scaled to different sizes depending on the display or use case.

Here are the key benefits of using SVGs for SCADA symbols:

Scalability: SVGs are vector-based, ensuring symbols can be scaled up or down without losing clarity or quality. This is crucial for industrial displays, which may vary from small control room screens to large wall-mounted panels.
Lightweight and Efficient: SVG files are generally smaller in size compared to high-resolution raster images, leading to faster load times and improved system performance.
Customizability: SVGs are written in XML, allowing for easy editing and customization. This flexibility enables engineers to tweak symbols for specific applications within the SCADA system.
Interactivity and Animation: SVG supports scripting and styling, enabling the creation of interactive or animated symbols that can visually represent real-time data changes.

A Glimpse into the SVG Language#

Creating SVG symbols involves defining shapes, paths, and styles using XML-based code. For instance, here’s a basic example of an SVG circle:

<svg width="100" height="100" xmlns="http://www.w3.org/2000/svg">
  <circle cx="50" cy="50" r="40" stroke="black" stroke-width="3" fill="red" />
</svg>

This simple code defines a red circle with a black border, easily customizable for any application. By leveraging the power of SVG, I’ve created a diverse range of symbols for iNDUS, from pumps and valves to turbines and other critical industrial components.

! Image Description

Note - The image shown is the output of the code above but its not an SVG so zooming in or out will change its quality. You can copy and paste the code in any online SVG editor to view the output or run locally.

Get Access to My Custom SVGs#

Some of the SVG symbols I’ve created for iNDUS SCADA will be made available for download on my Patreon page. If you’re looking for high-quality, scalable symbols for your system, be sure to check them out. Additionally, if you require custom SVG designs tailored to your specific needs, feel free to contact me. I’d be more than happy to help bring your ideas to life.

Conclusion#

SVGs are revolutionizing the way visuals are implemented in SCADA systems like iNDUS, offering unmatched scalability, efficiency, and customization. As industrial automation continues to evolve, embracing such cutting-edge technologies ensures systems remain adaptable and future-ready. Whether you’re working on iNDUS or any other SCADA platform, leveraging SVG symbols can significantly enhance your system’s visual and functional capabilities.

Explore my work on Patreon or get in touch for custom designs, and let’s push the boundaries of industrial visualization together!
